UNC 15 Periodontal Probe

The UNC 15 periodontal probe is graduated 1 to 15 mm in 1 mm steps, with dark bands at 4-5, 9-10 and 14-15 mm, and it is the probe for full-mouth periodontal charting where millimetre-precise pocket depths are recorded. Zepf makes it as a complete instrument and as interchangeable inserts for its handle systems. Helmut Zepf makes it in 8 configurations plus 4 replacement inserts, all in Germany, and every one on this page ships from our US warehouse.

Which UNC 15 Periodontal Probe Do You Need?

Clinical Use of the UNC 15 Periodontal Probe

• Full-mouth periodontal charting where millimetre-precise pocket depths are recorded.
• Technique: walk the probe around each tooth with light pressure (about 20 to 25 g), keeping the tip in contact with the root and the shank parallel to the long axis, and read the depth at the gingival margin.
• Reading: read the graduation against the gingival margin at each of the six sites per tooth and record the deepest reading per surface.

Versions, Coatings and Handles

Titanium working ends are for use around implants, where steel would mark the implant surface. The ZEPF-bIONIK handle is Zepf’s ergonomic, colour-coded handle with a textured grip that reduces hand fatigue. TOUCHGRIP is the Hürzeler / Zuhr series built for rotational control in surgical work, with matte working tips. Interchangeable inserts fit the M4 × 0.5 mm and M2.5 Zepf handle systems (ZEPF-bIONIK QUICKFIX, Z-SHAPE Relax, ZEPF-Line) and change with the Zepf safety key.

Sharpening, Retipping and Inserts

An instrument earns its keep only while it is sharp. Zepf instruments can be sharpened in the practice, sent to our sharpening and reconditioning service, or, on the interchangeable-insert versions, renewed in seconds by swapping the working ends. Sharpening stones and oil are in the diagnostic range.

Warranty and Our Guarantee

Every Zepf instrument on this page carries a one-year Helmut Zepf Warranty against defects in materials and workmanship. And because an instrument can only be judged in the hand, you have 60 days to return it for any reason — even after you have used it. Try it on real patients; if it is not the instrument for you, send it back.

Made in Germany by Helmut Zepf

Helmut Zepf has manufactured dental and surgical instruments in Germany for over 100 years. Every instrument on this page is forged, ground and finished by Zepf and carries its part number for traceability.

Compare With

Base pattern designations shown. Same clinical pattern, not identical manufacture. Brand names belong to their owners and are used only to identify the pattern; no affiliation or endorsement is implied.

FAQ

How is the UNC 15 graduated? 1 to 15 mm in 1 mm steps, with dark bands at 4-5, 9-10 and 14-15 mm.

When do I use the UNC 15 rather than another probe? Full-mouth periodontal charting where millimetre-precise pocket depths are recorded.

Are the inserts interchangeable? Yes: the probe inserts screw into the M4 × 0.5 mm and M2.5 Zepf handle systems and change with the safety key.

Is there a warranty? One year under the Helmut Zepf Warranty, and 60 days to return it for any reason, even after use.
