Gracey Curette, M5 Deep Scaling (GRA 1/2) for Front Teeth, Slightly Angled - ZEPF-bIONIK Handle in Yellow with Nanopal Coating | Helmut Zepf No. 24.201.01GM5OX

The Gracey Curette M5 Deep Scaling variant (GRA 1/2) is a precision periodontal instrument engineered for effective subgingival scaling and root planing on anterior teeth. Designed with a slightly angled blade geometry, this instrument delivers controlled access to the front teeth region, enabling clinicians to remove calculus and biofilm with accuracy and confidence.

ZEPF-bIONIK Handle with NANOPAL Coating

This Gracey Curette is fitted with the ZEPF-bIONIK handle in yellow, engineered to support ergonomic grip and reduce hand fatigue during extended clinical procedures. The handle's distinctive form factor promotes a balanced, secure hold, while the ZEPF NANOPAL coating enhances instrument longevity and facilitates thorough cleaning and sterilization between uses.

Key Features

• Gracey Special Curette configuration: 1/2 (GRA 1/2)
• M5 deep scaling blade for effective subgingival instrumentation
• Slightly angled design optimized for anterior (front) teeth
• ZEPF-bIONIK handle in yellow for ergonomic control
• ZEPF NANOPAL coating for enhanced surface durability and hygiene
• Manufactured by Helmut Zepf (Item No. 24.201.01GM5OX)
• Made in Germany

Clinical Application

As a site-specific Gracey Curette, the M5 GRA 1/2 is intended for use on anterior teeth, addressing both facial and lingual surfaces. The slightly angled blade facilitates adaptation to root contours in the anterior region, supporting thorough and minimally traumatic debridement in periodontal maintenance and active therapy. Clinicians relying on a high-quality Gracey Curette for anterior instrumentation will find the M5 GRA 1/2 well-suited to demanding subgingival access requirements.

Award-Winning Handle Design

The bIONIK handle won the Red Dot Design Award in 2010, the year of its launch. The jury of the Design Zentrum Nordrhein Westfalen in Essen, Germany, honored the bIONIK handle’s ergonomic design, high-tech material, and exceptional lightness and durability.

1-Year Warranty

This Helmut Zepf instrument is covered by a 1-year warranty against defects in materials and workmanship from the date of delivery.

60-Day Returns — Any Reason, Even If Used

Put this instrument to work in your practice. If it is not right for you, return it within 60 days of delivery for a full refund — for any reason, even if it has been used.

FAQ

What does the M5 designation indicate? M5 refers to the deep scaling blade specification of this Gracey Curette, suited for subgingival access in deeper pockets.

Is this instrument Made in Germany? Yes, this instrument is manufactured in Germany by Helmut Zepf.

What is NANOPAL coating? NANOPAL is a surface coating applied by ZEPF to improve instrument durability and facilitate cleaning and sterilization.

Which tooth surfaces does the GRA 1/2 address? The GRA 1/2 configuration is designed to treat both facial and lingual surfaces of anterior (front) teeth during periodontal scaling and root planing procedures.

Compare With

Base pattern designations shown. Same clinical pattern, not identical manufacture — see our Hygiene Instrument Comparison Chart.

Design Notes

The M5 design: the first shank is about 3 mm longer than standard and the sharpened working end is shortened, with a 0.95 mm thin, flexible and therefore highly tactile first shaft — built for special subgingival curettage in tight, deep pockets (beyond 5 mm) and along narrow root surfaces. Manufacturer literature (PDF).

Nanopal® coating: the black crystalline nano-coating raises surface hardness to 4,500 Vickers — the highly tempered cutting edge stays aggressive and sharp far longer and does not need resharpening after each curettage, while the scratch-resistant black surface is easy to clean and prevents light reflections. Manufacturer literature (PDF).
