ZEPF Z-SHAPE QuickFix Gracey M5 Deep Scaling Hygiene Instrument Set with NANOPAL Coating | Helmut Zepf No. 24.989.55OX
The Gracey Dental Hygiene Instrument Set from Helmut Zepf brings together a comprehensive selection of precision instruments engineered for professional prophylaxis and periodontal care. Designed for clinical efficiency, this set includes Gracey curettes 1/2, 7/8, 11/12 and 13/14 in the M5 deep-scaling design, a #204 S sickle scaler, and the ZEPFcare 1/3 washtray ā covering all essential scaling and root planing needs.
Z-SHAPE Relax ring color code
Z-SHAPE Relax handles are black; the colored ring next to the tip identifies which instrument you are using. Each ring color stands for a working-end pattern, so you can pick the right curette or scaler from the tray at a glance.
| Ring color | Instrument |
|---|---|
| Yellow | Gracey 1/2 M5 |
| Champagne | Gracey 7/8 M5 |
| Signal purple | Gracey 11/12 M5 |
| Cobalt blue | Gracey 13/14 M5 |
| Yellow-green | Sickle scalers 204S, 204SD, M23A |
Part of the Helmut Zepf QuickFix replaceable-tip system — screw-in tips for bIONIK, Z-SHAPE and Lotus handles. Swap a worn tip in seconds and keep the handle.
Backed by our Helmut Zepf Warranty — this instrument is warranted against defects in materials and workmanship for 1 year. Full terms and how to make a claim are on the Warranty page.
Instruments Included
| Product No. | Product |
|---|---|
| 24.221.01GM5OX | Gracey Curette (GRA 1/2) - M5 Replaceable Tips, Yellow Tip, Z-SHAPE Relax QuickFix Handle with Nanopal Coating |
| 24.225.07GM5OX | Gracey Curette (GRA 7/8) - M5 Replaceable Tips, Champagne Tip, Z-SHAPE Relax QuickFix Handle with Nanopal Coating |
| 24.224.11GM5OX | Gracey Curette (GRA 11/12) - M5 Replaceable Tips, Signal Purple Tip, Z-SHAPE Relax QuickFix Handle with Nanopal Coating |
| 24.227.13GM5OX | Gracey Curette (GRA 13/14) - M5 Replaceable Tips, Cobalt-Blue Tip, Z-SHAPE Relax QuickFix Handle with Nanopal Coating |
| 24.228.04SOX | Sickle Scaler #204 S - M5 Replaceable Tips, Yellow-Green Tip, Z-SHAPE Relax QuickFix Handle with Nanopal Coating |
| 85.182.00 | ZEPF Washtray 1/3 for 5 Instruments, with 2 Instrument Supports and 1 Retainer, 178 x 90 x 24 mm |
Z-SHAPE Relax Handle
Every instrument in this Gracey Dental Hygiene Instrument Set features the Z-SHAPE Relax Handle, an ergonomically optimised grip design developed to reduce clinician fatigue during extended treatment sessions. The handle geometry supports a neutral wrist position, contributing to improved tactile feedback and instrument control across all tooth surfaces.
ZEPF NANOPAL Coating
All instruments are finished with ZEPF NANOPAL Coating, a surface technology engineered to enhance corrosion resistance, facilitate sterilization, and maintain long-term sharpness retention. This coating contributes to the durability and consistent performance that dental hygienists and periodontists demand in a professional-grade Gracey Dental Hygiene Instrument Set.
Made in Germany
Helmut Zepf instruments are manufactured in Germany to exacting quality standards, reflecting decades of expertise in dental instrument production.
Design Notes
The M5 design: the first shank is about 3 mm longer than standard and the sharpened working end is shortened, with a 0.95 mm thin, flexible and therefore highly tactile first shaft ā built for special subgingival curettage in tight, deep pockets (beyond 5 mm) and along narrow root surfaces.
NanopalĀ® coating: the black crystalline nano-coating raises surface hardness to 4,500 Vickers ā the highly tempered cutting edge stays aggressive and sharp far longer and does not need resharpening after each curettage, while the scratch-resistant black surface is easy to clean and prevents light reflections.
1-Year Warranty
This Helmut Zepf instrument is covered by a 1-year warranty against defects in materials and workmanship from the date of delivery.
60-Day Returns ā Any Reason, Even If Used
Put this instrument to work in your practice. If it is not right for you, return it within 60 days of delivery for a full refund ā for any reason, even if it has been used.
FAQ
What instruments are included in this Gracey Dental Hygiene Instrument Set?
Five Z-SHAPE Relax QuickFix Nanopal instruments ā Gracey M5 curettes 1/2 (24.221.01GM5OX), 7/8 (24.225.07GM5OX), 11/12 (24.224.11GM5OX) and 13/14 (24.227.13GM5OX), plus the #204 S sickle scaler (24.228.04SOX) ā together with the ZEPFcare 1/3 washtray (85.182.00).
What is ZEPF NANOPAL Coating?
It is a surface treatment applied to all instruments to enhance corrosion resistance and support sterilization durability.
What is the Z-SHAPE Relax Handle designed for?
It is engineered for ergonomic comfort, reducing hand fatigue and improving control during clinical procedures.
